Total  Energy Conservation Products

Pumps



For All Applications



Geothermal Loops - Zones - Circulating - Well - Sump - Booster

Text Box: (512) 704-8200
Text Box: (512) 704-8200
Text Box: (512) 704-8200
Text Box: (512) 704-8200

Geothermal Loop Pumps



These pump modules are self contained. A all in one package pump system with a built in reservoir Designed for Geothermal Applications.



Several designs to handle all loops  large and small. Models sized with single, duplex, and twin pump systems.



The built in  reservoir allows the system to add fluid to the loop while removing any access air that may be trapped/



Built with Grundfos Pumps proven to be the leader in the industry.



Part Number-J100A3
Item Weight-15.2 pounds
Product Dimensions-17 x 9.3 x 8.9 inches
Item model number-J100A3

Sump Pump

Call for Pricing & Availability



(229) 638-2889



(512) 704-8200

The Everbilt 1/2 HP shallow-well jet pump has a pre-wired pressure switch 30/50 psi for automatic operation and self-primes after the housing is initially filled with water. The fiberglass-reinforced thermoplastic pump housing resists corrosion. This pump comes ready to install and is designed for wells with pumping levels of 25 ft. or less. This jet pump has a fan-cooled and dual voltage 115/230-volt motor. Thermoplastic pump housing for rust free Superior performance at depths to water of 25 ft. or less Heavy-duty dual-voltage 115/230-volt motor, pre-set at 230-volt Self-priming after pump housing is initially filled. Discharge Flow 0 ft. @ 40 PSI (gallons/hour) 432 Discharge Flow 15 ft. @ 40 PSI (gallons/hour) 330 Discharge Flow 25 ft. @ 40 PSI (gallons/hour)

This portable sump pump is a necessity of every house. Never worry again that your dry basement will be effected on rainy days or any day that the underground water table rises. Submersible sump pumps sit in a water- accumulating sump pit, they pump all excess water away from the house's foundation. This sump pump's advantage is that it has a higher base plate which assures the prevention of debris collection in the sump pit. - ˝ HP - Maximum flow of 2,000 gallons of water per hour - Adjustable tether switch - Multi fitting elbow - Extra long cord - Sealed specially in order to prevent electrical short circuits while under water. - Portable, does not have to be permanently installed. The purchase of this sump pump will save any home owner thousands of dollars by preventing water in the home's basement

· Product Dimensions: 13 x 6.5 x 8.8 inches

· Item model number: SM10102

· Voltage: 115 volts

· Horsepower: 0.5 HP

· Shipping Weight: 8.7 pounds

· Powered By A Durable, Oil-Cooled Electric Motor

· Max Submersion Depth: 16.5FT

· Various Fittings for Outflow Included

· Max Delivery Height: 23FT



Booster Pump

Electric Shallow Well water pump 1.6 HP 1200W Suction Height 25ft 1000Gallon Per Hour

Transfer water from wells, up moderate slopes and to the upper stories of buildings.

Braided  steel tank hose, ,Steel pressure tank with gauge. Self-priming, Thermal protection

· Power Voltage: 115V / 60Hz

· Above-Ground / On-Ground

· 1.6 HP Long Lasting Motor

· 1-1/4" Female Pipe Thread Connections inlet and outlet Fitting

· Max Suction Height 25ft.

· Max. Lift height: 166FT

· Max pressure: 4.0bar

· Max Head 35m

· Max flow rate: 1000GPH

· Aporx 3Ft Long Power Cord

· Fluid Temperature Up To 35 Deg C..

· Maximum Ambient Temperature 35 Deg C.

· Drain Plug For Easy Maintenance Of Pump Corrosion-Proof
